12.88" Superlite Big Brake Brake Kit- 06-15 NC Miata / 04-11 RX8

Forged Narrow Superlite 6R Big Brake Front Brake Kit – NC 2006-2016 Mazda Miata 04-11 RX8

Upgrade your Miata's stopping power with the Forged Narrow Superlite 6R Big Brake Front Brake Kit. Engineered for NC 2006-2016 Miatas, this premium brake kit delivers race-inspired performance while enhancing your vehicle’s safety and control.

• Ultimate Stopping Power: Featuring a lightweight, forged 6-piston caliper design, this brake kit ensures optimal clamping force, superior heat dissipation, and long-lasting reliability.
• Precision Fitment: Tailored specifically for NC Miatas (2006-2016), providing perfect compatibility without the need for modifications.
• Performance Rotors: Comes with high-performance rotors designed to resist warping and provide consistent braking performance in extreme conditions.
• Complete Kit: Includes calipers, rotors, pads, and all necessary mounting hardware for a seamless installation.

Whether you’re hitting the track or cruising the streets, experience unmatched braking confidence with the Forged Narrow Superlite 6R kit.

Wilwood install video

https://youtu.be/RbIUtPkTWSc

Wheel fitment:

Enkei PF01 17x8 +45: OK
Enkei PF01 17x8 +50: OK
Enkei PF01 17x9: OK
Enkei RPF1 17x8: NO
Enkei RPF1 17x9: NO
Enkei RPF1 17x10: OK

Konig Hypergram 17x8 +35: OK
Konig Hypergram 17x9: OK
Konig Hypergram 18x8.5: OK
Konig Ultraform 17x8: OK
Konig Ultraform 17x9: OK
Konig Ampliform 17x8: OK
Konig Ampliform 17x9: OK
Konig Heliogram 17x8.5: OK
Konig Dekagram 17x8: OK
Konig Dekagram 17x9: OK

949Racing 6UL 17x9: OK
949Racing 6UL 17x10: OK

Advanti Storm S1 17x8: OK
Advanti Storm S1 17x9: OK

Wilwood part numbers

140-12907

140-12907-D

140-12907-DR

140-12907-R
